How the pieces talk
Manager owns privileged control-plane decisions. Nexus owns the tenant's agent workflow. Coder runs workspaces, and Redis stores tenant coordination state. The channel determines the credential and authority.
| Channel | Authentication | What travels over it |
|---|---|---|
| Nexus → Manager | Workspace runtime access token | Worker requests, status, heartbeats, and GitHub credential requests |
| Manager → Coder | Platform operator credential | Template publication and workspace creation or lifecycle |
| Runtime → Redis | Tenant Redis ACL credential | Ticket state, worker slots, heartbeats, A2A evidence |
| Coder → Manager → Nexus | Global then tenant hook JWT | Coder lifecycle events and policy responses |
| Forge / Sentinel → Nexus | Ticket pair token | A2A verification tasks, progress, and results |
| Runtime → GitHub | Brokered installation token | Repository API and Git operations |
Runtime API
Each workspace registers using a one-time bootstrap and receives an access/refresh pair. Manager derives its tenant, role, and repository from the workspace record. Nexus asks Manager to create workers; Manager records a durable operation and talks to Coder.
Hooks and A2A
Coder lifecycle events enter through Manager, which authenticates and routes them to the tenant's Nexus hook server. Agent CLI hooks run locally inside worker workspaces. Sentinel and Forge exchange verification tasks through Nexus's A2A relay, which persists evidence to tenant Redis.
Read Manager Runtime, Credentials and Trust, and Hooks and A2A for the full request flows.
